Automatic Pouch Filling and Sealing Machine for Leak-Proof Liquid Pouches

Product Code: UMEO-420Y

Key Features:

  • Four-side sealing liquid VFFS machine engineered for 100% leak-proof pouches
  • Reinforced four-edge sealing prevents liquid leakage and spillage
  • Ideal for water, juices, sauces and other liquid products in pouch packaging

Description


Four-side sealing liquid packing machine

  • Automatically for feeding, weighing, forming, degassing valve punching, filling, output conveying.

  • Imported PLC with colorful touch screen control system,multilingual function,easy to operate.

  • Servo motor for film feeding,photocell eye tracking for precise positioning.

  • Intelligent temperature control system,automatically rectification function.

  • Multifunctional alarm function to reduce wastage,safe operation.

Video



Specification


ModelUMEO-420Y
Bag Length50-300mm
Bag Width50-200mm
Film Width (Max.)420mm
Packing Speed900-1500 packet/h
Gas Consumption0.8 m³/min
Power3.5KW
Voltage220V/380V, AC 50/60HZ  1P/3P
Bag TypePillow bag,linking-bag,side-sealing bag
Roll FilmExtermal Dia.≤320mm, inner dia.≥76mm
Working Pressure0.8MPa
Net Weight590KG
Packaging Filmlaminated film (OPP/CPP,OPP/CE,PET/PE,Aluminium foil,PE/PE etc)
